举例来说 ¶

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
    NAME "Europe in purple"
    SIZE 400 400
    STATUS ON
    SYMBOLSET "/var/www/html/maps/symbols/symbols.sym"
    EXTENT -5696501 1923039 5696501 11022882
    UNITS METERS
    SHAPEPATH "/var/www/html/maps/data"

    WEB
        IMAGEPATH "/var/www/html/maps/tmp/"
        IMAGEURL "/tmp/"
    END

    LAYER
        NAME "Europe"
        TYPE POLYGON
        STATUS ON
        DATA "europe"
        CLASS
            STYLE
                COLOR 110 50 100
                OUTLINECOLOR 200 200 200
                SYMBOL 0
            END
        END
    END

    END

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
    <?php

    dl('php_mapscript.so');

    $map_path="/var/www/html/ms/map_files/";

    $map = ms_newMapObj($map_path."europe.map");
    $image=$map->draw();
    $image_url=$image->saveWebImage();

    ?>

     <HTML>
      <HEAD>
          <TITLE>Example 1: Displaying a map</TITLE>
      </HEAD>
      <BODY>
          <IMG SRC=<?php echo $image_url; ?> >
      </BODY>
     </HTML>

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
    <?php

    dl('php_mapscript.so');

    // Default values and configuration

    $val_zsize=3;
    $check_pan="CHECKED";
    $map_path="/var/www/html/ms/map_files/";
    $map_file="europe.map";

    $map = ms_newMapObj($map_path.$map_file);


    if ( isset($_POST["mapa_x"]) && isset($_POST["mapa_y"])
          && !isset($_POST["full"]) ) {

          $extent_to_set = explode(" ",$_POST["extent"]);

          $map->setextent($extent_to_set[0],$extent_to_set[1],
                          $extent_to_set[2],$extent_to_set[3]);

          $my_point = ms_newpointObj();
          $my_point->setXY($_POST["mapa_x"],$_POST["mapa_y"]);

          $my_extent = ms_newrectObj();

          $my_extent->setextent($extent_to_set[0],$extent_to_set[1],
                                  $extent_to_set[2],$extent_to_set[3]);

          $zoom_factor = $_POST["zoom"]*$_POST["zsize"];
          if ($zoom_factor == 0) {
                  $zoom_factor = 1;
                  $check_pan = "CHECKED";
                  $check_zout = "";
                  $check_zin = "";
          } else if ($zoom_factor < 0) {
                  $check_pan = "";
                  $check_zout = "CHECKED";
                  $check_zin = "";
          } else {
                  $check_pan = "";
                  $check_zout = "";
                  $check_zin = "CHECKED";
          }

          $val_zsize = abs($zoom_factor);

          $map->zoompoint($zoom_factor,$my_point,$map->width,$map->height,
                          $my_extent);

     }


     $image=$map->draw();
     $image_url=$image->saveWebImage();

     $extent_to_html = $map->extent->minx." ".$map->extent->miny." "
                  .$map->extent->maxx." ".$map->extent->maxy;

     ?>
     <HTML>
     <HEAD>
     <TITLE>Map 2</TITLE>
     </HEAD>
     <BODY>
     <CENTER>
     <FORM METHOD=POST ACTION=<?php echo $HTTP_SERVER_VARS['PHP_SELF']?>>
     <TABLE>
     <TR>
          <TD>
                  <INPUT TYPE=IMAGE NAME="mapa" SRC="<?php echo $image_url?>">
          </TD>
     </TR>
     <TR>
          <TD>
                  Pan
          </TD>
          <TD>
                  <INPUT TYPE=RADIO NAME="zoom" VALUE=0 <?php echo $check_pan?>>
          </TD>
     </TR>
     <TR>
          <TD>
                  Zoom In
          </TD>
          <TD>
                  <INPUT TYPE=RADIO NAME="zoom" VALUE=1 <?php echo $check_zin?>>
          </TD>
     </TR>
     <TR>
          <TD>
                  Zoom Out
          </TD>
          <TD>
                  <INPUT TYPE=RADIO NAME="zoom" VALUE=-1 <?php echo $check_zout?>>
          </TD>
     </TR>
     <TR>
          <TD>
                  Zoom Size
          </TD>
          <TD>
                  <INPUT TYPE=TEXT NAME="zsize" VALUE="<?php echo $val_zsize?>"
                  SIZE=2>
          </TD>
     </TR>
     <TR>
          <TD>
                  Full Extent
          </TD>
          <TD>
                  <INPUT TYPE=SUBMIT NAME="full" VALUE="Go"
                  SIZE=2>
          </TD>
     </TABLE>
     <INPUT TYPE=HIDDEN NAME="extent" VALUE="<?php echo $extent_to_html?>">
     </FORM>
     </CENTER>
     </BODY>
     </HMTL>
